Direct Sequence Spreading Spectrum (DSSS) modulation
Crystal clear stereo CD quality with uncompressed technology
Very short delay time < 2ms
Up to 100m line of sight distance (depending on antenna type and transmitting output power)
Operate on 2.4GHz unlicensed ISM band
Support RF channel auto scan and synchronization
Support antenna diversity receiving
Support 16bit, 44.1KHz digital audio transmission over the air
Support multi-level mute function
Support auto power down function after 5 minutes of no audio input (adjustable)
Support 7bit manufacture ID (available on request)
Support 24bit user ID
Support User ID learning function
Broadcast to unlimited receivers by same User ID
Receiver support 128 steps volume control function
Receiver is compatible to multiple transmitter sources, such as analog, S/PDIF and USB
Sleeping Mode
RF channel auto scan and synchronization
Multiple Audio Interface : I2S, S/PIF, USB, Analog
  Specifications
  specification


Power supply voltage range : 3.6 ~ 5VDC Power Consumption : 350mA
Compatible with Win98 SE / Win ME / Win 2000 / Win XP without additiond driver
Compliant with USB audio device class specification v1.0
